Case Study 5 - Materials Recovery Facility (MRF)



General Information Photo Gallery
Name: MRF of Elefsina case study 5


case study 5
Owner: Hellenic Recovery & Recycling Corporation
Operator: Alpha Green Sa
Technology: MRF
Designed Capacity: n/a
Cost: 5.39 million € (total investment cost)
Location: Elefsina, Greece
Served Area: (below)
Commercial Start Up: 2009
Contact Details
Address: 1) Hellenic Recovery & Recycling Corporation
Chimaras st. Maroussi
15125, Athens, Greece

2) Alpha Greeb SA
Ag.Polikarpou 57, Athens Greece
Phone Number: 1) +30 210 8010962
2) +30 210 2828967
Fax: -
Email: info@herrco.gr
Website: www.herrco.gr



Short Description

The MRF Plant of Elefsina is the principal member of the recycling scheme of blue bins developed in the municipality of Elefsina. The scheme, which serves 310,405 residents, includes 5,018 blue bins for recyclable materials and 14 vehicles for the collection.

The plant occupies an area of 2,112 m2 and has been in operation since 2009.

The plant includes the following main parts:

  • One Trommel
  • Two lines with conveyor belts for handpicking
  • Two electromagnets
  • Two NIR separators
  • One ballistic separator

In 2010 the plant operated 2,496 hours and recovered 12,982 tons of recyclable materials. About 30% of the recovered recyclables are reclaimed at local recycling companies whereas the rest are exported.



Key Facts

Treatment Capacity: 20,004 tpa (Data of the year 2010)
Input Material: Mixed Packaging Waste & printing paper from households (blue bins) 20,004 tpa
Packaging paper/Cardboard 24.4%
Printed paper 28%
Rest paper (tetrapack) 0.7%
Packaging plastic 7%
Rest plastics 1.1%
Ferrous metals 2%
Aluminum 0.3%
Other non ferrous metals 0.8%
Glass 0.9%
Wood 0%
Other recyclables 0.7%
Residues 35.1%
Output Products: Packaging 4,879 tpa
Printing Paper 5,592 tpa
Rest no-packaging 135 tpa
Cardboard 37.6%
Printed paper 43.1%
Rest paper (tetrapack) 1.1%
PET 3.3%
HDPE 1.6%
PVC 0%
LDPE 6%
Rest plastics 1.8%
Ferrous metals 3.1%
Aluminum 0.4%
Other no ferrous metals 1%
White glass 0%
Coloured glass 1.2%
Wood 0%
Other recyclables 1.56%
Residues to final disposal 7,016 tpa



Extra Information

Plant Process Data
Number of Trommels 1
Total recovery capacity of trommels 7,000 kg/h
Number of magnets 2
Total recovery capacity of magnets 3,000 kg/h
Number of handpickers 20
Total recovery capacity of handpickers n/a
Number of NIR separators 2
Total recovery capacity of NIR separators 2,300 kg/h
Number of ballistic separators 1
Total recovery capacity of ballistic separators 3,000 kg/h
